Upgraded features from M-Radon V2.1:


. Change to 32-bit MCU with ultra-smooth, faster response with precise throttle and braking control. More top end power with the same item function setup.
. Support ~2.5A BEC ampere drawn which is raised up by ~60%.
. Support ~30A instant ampere drawn by the motor which is raised up by ~50%.
. All wire are exposed to open area for easy soldering.
. Built-in Bluetooth device for advanced programming and firmware update through the Mobile APPS.
. APPS will be available on both IOS and Android.
. Real Time Data Analysis through Mobile APPS(Current Input & Output Throttle, Temperature, RPM, Adv. Timing, Voltage and min. voltage, Max Temperature, RPM & Adv. Timing).



Software:
. It is a new developed software with more advanced item functions added which is closed to the same as Radon Pro V5BT.
. Each item have small step to fine tune.
. All update item functions information can be reviewed from the photos attached.

Specification:
 Sensor type
- Shaft Diameter: 2mm
- Weight: ~14~15g (vary in different KV Motor)
- Available KV: 3500KV, 4500kv, 5500KV, 6000KV
- Recommended RC Model Car: 1/28 Miniz car

- Battery Input Voltage: 2S lipo
- BEC: 6V/2.5A
- 1/27 motor Limit: 10000kv or below
- Max Ampere draw: ~30A per phase
- Size: ~22.5x13.5x9mm(not include the plug)
- Weight: ~5g(without any wire installed)

User Manual Download(Eng Ver):
https://drive.google.com/file/d/1X3nHJrWUUl_9s_mK7D2y2MKIE5FEkS6T/view


Mode Description Manual Download(Eng Ver):
https://drive.google.com/file/d/1jl6aExzfqP6bknMXTE_yYvWmVRTCtxf2/view
